| Brand Name: | Chitherm |
| Model Number: | Htf4572-0611nh |
| MOQ: | 1 |
| Price: | Negotiable |
| Delivery Time: | Customized |
| Payment Terms: | Customized |
| Attribute | Value |
|---|---|
| Range of Applications | Industrial |
| Type | Electric Holding Furnace |
| Usage | Steel Molding |
| Fuel | Electric |
| Furnace Tube Dimensions | Φ45(Od)*5*7200mm(L) |
| Transport Package | Wooden Packaging |
| Specification | 14850*950*1460mm(L*W*H) |
| Trademark | Chitherm |
| Origin | China |
| HS Code | 8514101000 |
| Supply Ability | 50 Sets/Year |
| Customization | Available |
| Certification | ISO |
| Place Style | Horizontal |
Electric Holding Furnace for Continuous Annealing in Industrial Production Process
The entire equipment is primarily composed of:
| Rated Temperature | 1100°C |
| Maximum Temperature | 1150°C |
| Furnace Tube Dimensions | Φ45 (OD) mm * 5 mm * 7200 mm (L) * 4, 310S stainless steel |
| Cooling Section Dimensions | Φ45 (OD) mm * 5 mm * 7200 mm (L) * 4, 304 stainless steel |
| Maximum Heating Power | 90 kW |
| No-load Holding Power | ≤45 kW |
| Heating Zone Length | 6000 mm |
| Effective Heating Zone Length | ≥3000 mm |
| Temperature Uniformity | Within ±3°C in effective heating zone |
| Tube Spacing | 80 mm |
| Heating Elements | Silicon Carbide (SiC) Heating Rods |
| Heating Method | Top & Bottom Heating |
| Number of Temperature Zones | 6 zones |
| Temperature Control Points | 6 points |
| Thermocouple Type | Type N (NiCr-NiSi) |
| Temperature Control Stability | ±1°C, with PID parameter self-tuning function |
| Process Atmosphere | Nitrogen/Hydrogen (N2/H2) |
| Gas Inlet Location | Between high-temperature zone and cooling section |
| Exhaust Outlet Location | At furnace tube inlet end |
| Maximum Heating Rate | 10°C/min |
| Cooling Method | Circulating Water Cooling in cooling zone |
| Outlet Water Temperature | ≤30°C |
| Transition Platform Length | ≥3500 mm |
| Take-up Speed | 300-2750 mm/min |
| Surface Temperature Rise | ≤35°C |
| Alarm & Protection | Audible & visual alarms for over-temperature, thermocouple breakage, low air pressure, low water pressure, motor overload, etc.; over-temperature alarm with heating cut-off protection |
| Overall Dimensions (Reference) | 14850 * 950 * 1460 mm (L * W * H), excluding transition platform and pay-off/take-up devices |
Actual dimensions subject to final product specifications.
| Category | Description | Qty |
|---|---|---|
| Basic Components | Kiln Main Unit | 1 set |
| Wire Take-up Machine | Four-axis Eight-spool | |
| Inspection Certificate | Certificates of conformance for major external components | |
| Technical documents | User Manual & Technical Documents for Major Purchased Components | |
| Critical Components | Silicon Carbide Heating Elements | Complete set |
| Temperature Controller | Imported from Japan | |
| Thermocouples | 6 units | |
| Water Chiller | Model CA-05 | |
| Spare Parts | Solid State Relay (SSR) | 1 unit |
